Jual GPS Geodetic Hitarget V90 Plus Di Kota Gorontalo

Deskripsi

GPS Geodetic Hitarget V90 Plus yaitu salah satu pilihan yang paling fleksibel untuk setiap tugas pengukuran. Built-in sistem operasi Linux3.2.0, pre-loaded beberapa aplikasi pintar seperti tilt survei, gelembung kalibrasi elektronik, NFC dan DIY suara, sistem V90 Ditambah GNSS menyediakan solusi GNSS surveyor industri terkemuka.

Kemudian dengan hi-tech, desain terintegrasi, dengan V90 Plus berukuran nyaman merupakan salah satu pilihan yang paling fleksibel untuk setiap tugas pengukuran. Built-in sistem operasi Linux3.2.0, pre-loaded beberapa aplikasi pintar seperti tilt survei, kalibrasi bubble elektronik, NFC dan DIY suara, sistem V90 Plus GNSS menyediakan solusi GNSS surveyor industri terkemuka.

Beli juga : Total Station Sokkia IM-52

GPS Geodetic Hitarget V90 Plus tersedia di Indosurta Manado dengan harga murah dan juga bergaransi resmi 1 tahun. Untuk pembelian silahkan hubungi kami atau bisa juga datang ke toko alat survey kami.

Spesifikasi GPS Geodetic Hi-Target V90+

Satellite Signals Tracked Simultaneously

220 Channels

• GPS: Simultaneous L1C/A, L2C, L2E, L5
• GLONASS: Simultaneous L1C/A, L1P, L2C/A (GLONASS M only), L2P
• BDS: B1, B2
• Galileo: Simultaneous E1 BOC, E5A, E5B, E5AltBOC
• SBAS: L1 C/A, L5

550 Channels (Optional)

• GPS: L1C/A, L1C, L2C, L2P, L5
• GLONASS: L1C/A, L2C, L2P, L3, L5
• BeiDou: B1, B2, B3
• Galileo: E1, E5A, AltBOC, E5a, E5B, E6
• IRNSS: L5
• SBAS: L1, L5
• QZSS: L1C/A, L1C, L2C, L5, L6
• L-band: Up to5 channels
• TerraStar Correction Services

Positioning Performance

• Hot Start: Typically< 10s
• Cold Start: Typically< 15s
• High Precision Static
  • Horizontal: 2.5 mm + 0.1 ppm RMS
  • Vertical: 3.5 mm + 0.4 ppm RMS

• Static and Fast Static
  • Horizontal: 2.5mm + 0.5 ppm RMS
  • Vertical: 5 mm + 0.5 ppm RMS

• Post Processing Kinematic (PPK / Stop & Go) GNSS Surveying
  • Horizontal: 8mm+1ppm RMS
  • Vertical: 15mm+1ppm RMS
  • Initialization time: Typically 10 min for base and 5 min for rover
  • Initialization reliability: Typically > 99.9%

Real Time Kinematic (RTK) Surveying

• Single Baseline
  • Horizontal: 8mm+1ppm RMS
  • Vertical: 15mm+1ppm RMS

• Code Differential GNSS Positioning
  • Horizontal: 25cm+1ppm RMS
  • Vertical: 50cm+1ppm RMS
  • SBAS: 0.5 m(H), 0.85 m(V)

• Network RTK
  • Horizontal: 8mm+0.5ppm RMS
  • Vertical: 15mm+0.5ppm RMS
  • Initialization time: Typically 2-10s
  • Initialization reliability: Typically > 99.9%

Communication

• Network Communication:
  • Fully integrated, fully sealed internal WCDMA, compatible with GPRS, GSM
  • Wifi frequency is 2.4G, supports the standard protocol 802.11b/g/n
  • Network RTK (via CORS) range 20-50km

Hi-Target Advanced Internal UHF Radio

• Frequency: 403-473Mhz
• Transmitting power: 1W,2W,4W adjustable
• Transmitting linkrate: 9.6Kbps, 19.2Kbps
• Support Multiple protocols:
• Working Range: Typically 3~5km, optimal 5~8km

SATEL Internal UHF Radio (Optional)

• Frequency: 403-473Mhz
• Transmitting power: 0.1W~1W adjustable
• Transmitting linkrate: 9.6Kbps, 19.2Kbps
• Support Multiple Communication protocols
• Working Range: Typically 3~5km, optimal 5~8km

Hi-Target External UHF Radio

• Frequency: 460MHz with 116 channels
• Transmitting power: 5W/25W adjustable
• Transmitting speed: Up to 19.2Kbps
• Working Range: Typically 8~10km, optimal 15~20km

Advanced External UHF Radio (Optional)

• Frequency: 41o-47oMhz
• Transmitting power: 5W/25W
• Compatible with third party radio
• Working Range: 8~10km typically, optimal 15~20km

Hardware

Physical

• Dimension (W x H): 153mm x 83mm (6.02inch x 3.27inch)
• Weight: 950g (2.09lb) without internal battery
• Operation Temperature: -40°C ~+ 75°C (-40°F ~+ 167 °F)
• Storage Temperature: -55°C ~+ 85°C (-67°F ~+ 185 °F)
• Humidity: 100%, condensing
• Water/dustproof: IP67 dustproof, protected from temporary immersion to depth of 1m (3.28ft)
• Shock and Vibration: Designed to survive a 2m (6.56ft) natural fall onto concrete

Electrical

• Power 6V to 28V DC external power input
• power consumption ≤ 3.5W
• Automatic switching between internal power and external power
• Rechargeable, removable 7.4V, 5000mAh Lithium-ion battery in internal battery compartment

Internal Battery Life

• Static more than 12 hours.
• RTK Base more than 8 hours.
• RTK Rover (UHF/GPRS/3G) for 10 hours.

I/O Interface

• Bluetooth, NFC, standard USB 2.0 port, TNC antenna connector
• RS232 serial port, DC power input (5-pin), MicroSD card port

Tilt Survey System

Electronic Bubble

WebUI

System Configuration

System

• Data Storage: 16GB Internal storage+ Internal Micro SD Card memory (Support up to 32GB extension)
• Record GNS and Rinex format simultaneously

Data Formats

• (1Hz positioning output, up to 50Hz – depends on installed option)
• CMR: sCMRx, CMR, CMR+input and output
• RTCM: RTCM 2.1, 2.2, 2.3, 3.0, 3.1, 3.2 input and output
• Navigation outputs ASCII: NMEA-0183 GSV, AVR, RMC, HDT, VGK, VHD, ROT, GGK, GGA, GSA, ZDA, VTG, GST, PJT, PJK, BPQ, GLL, GRS, GBS
• Navigation outputs binary: GSOF
