GPS Geodetic Hi-Target iRTK4 GNSS RTK

Deskripsi

Lihat Brosur :Brosur GPS Geodetic/GNSS Hi-Target iRTK 4

GPS Geodetic Hi-Target Irtk4 adalah sistem Receiver GNSS yang cerdas serta memiliki beberapa fitur lengkap, serta dilengkapi dengan antena berfrekunsi penuh generasi terbaru dan terintegrasi dan mesin multi-chanel canggih.

Sehingga dapat membantu pengguna /surveyor untuk mendapatkan koreksi yang akurat dan andal. Pengguna dari Geodetic Irtk4 ini juga dapat mengambil keuntungan dari survey kemiringan bebas kalibrasi tanpa harus meratakan tiang survey untuk mengumpulkan data.

Indosurta Manado jual GPS Geodetic Hi-Target iRTK4 GNSS RTK dengan harga murah dan juga bergaransi resmi 1 tahun. Untuk pembelian silahkan hubungi kami atau bisa juga datang ke toko alat survey kami.

Spesifikasi GPS Geodetic Hi-Target iRTK4 GNSS RTK

Satellite Signals Tracked Simultaneously

• Channels: 1408
• GPS: L1, L2, L5
• GLONASS: L1, L2
• BDS: B1, B2, B3
• Galileo: E1, E5a, E5b
• QZSS: Support
• SBAS: Support
• Global correction service: Hi-RTP (optional)

Positioning Performance

• High Precision Static GNSS Surveying
  • Horizontal: 2.5 mm + o.5 ppm RMS
  • Vertical: 5 mm + 0.5 ppm RMS

• Real Time Kinematic (RTK)
  • Horizontal: 8mm+1ppm RMS
  • Vertical: 15mm+1ppm RMS

• Tilt Survey Performance
  • 2cm accuracy in the inclination of 30 degree
  • 3cm accuracy in the inclination of 45 degree

• DGPS
  • Horizontal: ±0.25m+1ppm RMS
  • Vertical: ±0.5m+1ppm RMS
  • SBAS: 0.5m
  • Initialization time: Typically <10s
  • Initialization reliability: Typically > 99.99%

Communication

• Bluetooth: 4.2/2.1 +EDR, 2.4GHz
• Network Communication:
  • 4G cellular mobile network (TDD-LTE, FDD-LTE, WCDMA, EDGE, GPRS, GSM)
  • Wifi frequency is 2.4G, support 802.11b/g/n protocol.

Internal UHF Radio

• Frequency: 410-470Mhz
• Channels: 116 (16 scalable)
• Transmitting power: 1 ~ 4W Hi-Target Advanced Radio
• Support Multiple protocols:
  • HI-TARGET
  • TRIMTALK450S
  • TRIMMARK III
  • TRANSEOT
  • SATEL-3AS,
  • etc.
• Working Range: Typically 3~5km, optimal 5~8km

External UHF Radio

• External HDL460A Full protocols Radio
• Frequency: 403~473MHz
• Channel: 116 (16 scalable)
• Transmitting power: 10W/35W adjustable
• Protocols: HI-TARGET, TRIMTALK450S, TRIMMARK III, TRANSEOT, etc.
• Working Range: Typically 8~10km, optimal 15~20km

Physical

• Internal Battery
  • Internal 7.4V/6800mAh lithium-ion rechargeable battery.
  • Charging: supports USB PD3.0 quick charge, Quick charge within 3.5 hours.
  • RTK Rover (Network) for 10 hours.

• External Power
  • 7-28V DC External power input (5-pin port) with over-discharge protection.
  • Power Consumption: 4.2 W
  • Support Power Bank charging.
  • Dimension (W x H): 156mm x 7mm
  • Weight: ≤ 1.2kg (includes battery)
  • Data storage: 8GB ROM internal storage

Control Panel

• Physical Button: 2
• LED Lamp: Satellite, Signal

Environment

• Water/Dustproof: IP68
• Shock and Vibration: Designed to survive a 2m natural fall onto concrete
• Humidity: 100%, condensing
• Operation Temperature: -30°C ~+ 70°C
• Storage Temperature: -40°C ~+ 80°C

I/O Interface

• 1 x USB Port, Type C, OTG function
• 1 x SMA antenna connector
• 1 x DC power input (5-pin)
• 1 x Nano SIM card slot

Data Formats

• Output Rate: 1Hz-20Hz
• Static data format: GNS, Rinex
• Network model: VRS, FKP, MAC; supports NTRIP protocol
• CMR& RTCM: CMR, RTCM 2.x, RTCM 3.0, RTCM 3.2
• Navigation Outputs ASC II: NMEA-0183

More Features

• IP68
• Full-frequency Antenna
• OLED
• NFC
• Magnesium Alloy Case

Layanan purna jual

• Garansi servis 1 tahun
• Gratis training alat
• Gratis pengiriman dan juga COD khusus Manado dan sekitarnya
