GPS RTK Geodetik Hi-Target V30+

Spesifikasi GPS RTK Geodetik Hi-Target V30+

• Satellite Signals Tracked Simultaneously

  • Channels: 800+
  • GPS: L1/L2/L5/L2C
  • GLONASS: L1/L2/L3
  • BDS: B1/B2/B3/B1C/B2a
  • Galileo: E1/E5 AltBOC/E5a/E5b/E6
  • SBAS: L1/L5
  • QZSS: L1/L2/L5/L6
  • NavIC (IRNSS): L5
  • Global correction service: Hi-RTP (optional)
  • Base and Rover: Interchangeable

• Positioning Performance

  • High Precision Static GNSS Surveying
    • Horizontal: 2.5 mm + 0.1 ppm RMS
    • Vertical: 3.5 mm + 0.4 ppm RMS

• • Static and Fast Static
    • Horizontal: 2.5mm + 0.5 ppm RMS
    • Vertical: 5 mm + 0.5 ppm RMS

• • Post Processing Kinematic (PPK / Stop & Go)
    • Horizontal: 8mm+1ppm RMS
    • Vertical: 15mm+1ppm RMS
    • Initialization time: Typically 10 min for base and 5 min for rover
    • Initialization reliability: Typically > 99.9%

• • Code Differential GNSS Positioning
    • Horizontal: 25cm+1ppm RMS
    • Vertical: 50cm+1ppm RMS
    • SBAS: 0.5 m(H), 0.85 m(V)

• • Network RTK
    • Horizontal: 8mm+0.5ppm RMS
    • Vertical: 15mm+0.5ppm RMS
    • Initialization time: Typically 2-10s
    • Initialization reliability: Typically > 99.9%

• • Real Time Kinematic (RTK)
    • Horizontal: 8mm+0.5ppm RMS
    • Vertical: 15mm+0.5ppm RMS

• • Hi-Fix
    • Horizontal: RTK + 10 mm/minute RMS
    • Vertical: RTK + 20 mm/minute RMS

• Communication

  • Bluetooth: 4.0/2.1 +EDR, 2.4GHz
  • Network Communication:
    • 4G cellular mobile network (TDD-LTE, FDD-LTE, WCDMA, EDGE, GPRS, GSM)
    • Wifi frequency is 2.4G, support 802.11b/g/n protocol.

• Internal UHF Radio

  • Frequency: 403-473Mhz
  • Channels: 116 (16 scalable)
  • Transmitting power: 1W/2W/4W adjustable
  • Support Multiple protocols:
    • HI-TARGET
    • TRIMTALK450S
    • TRIMMARK III
    • TRANSEOT
    • SATEL-3AS,
    • etc.
  • Working Range: Typically 3~5km, optimal 5~8km

• External UHF Radio

  • Frequency: 410~470MHz
  • Channel: 8
  • Transmitting power: 5W/25W adjustable
  • Support Multiple Protocols: TRIMTALK450S, TRIMMARK III, TRANSEOT

• Power Supply

  • Internal Battery
    • 5000mAh lithium-ion rechargeable and removable battery.
    • RTK Rover (UHF/Celullar) for 10 hours.

• External Power
  • • 6-28V DC External power input (5-pin port) with over-charge protection.
    • Power Consumption: 4.2 W

• Physical

  • Dimension (W x H): 164mm x 83.5mm
  • Weight: ≤ 1.4kg (includes battery)
  • Data storage: 8GB ROM internal storage

• Control Panel

  • Physical Button: 1
  • LED Lamp: Satellite, Signal, Power

• Environment

  • Water/Dustproof: IP67
  • Shock and Vibration: Dsurvive a 2m natural fall on to ground
  • Humidity: 100%, condensing
  • Operation Temperature: -45°C ~+ 75°C
  • Storage Temperature: -55°C ~+ 85°C

• I/O Interface

  • 1 x Mini USB Port
  • 1 x TNC antenna connector
  • 1 x DC power input (5-pin)
  • 1 x SIM card slot

• Data Formats

  • Output Rate: 1Hz-20Hz
  • Static data format: GNS, Rinex
  • Network model: VRS,  supports NTRIP protocol
  • CMR& RTCM: CMR, RTCM 2.x, RTCM 3.0, RTCM 3.2
  • Navigation Outputs ASCII: NMEA-0183
